RRP $183.30
$175.07
SAVE $8.23 (4%)
In Stock


Calculate Shipping

Dahua Seagate Skyhawk 3TB Hard Drive





Best-Fit Applications

    • Network video recorders (NVR)
    • Embedded surveillance DVRs (SDVR)
    • Hybrid surveillance DVRs
    • Surveillance DVRs





The Blurb:

SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.





Key Advantages

ImagePerfect firmware

ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads that record video from 64 HD cameras.

SkyHawk Health Management

SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.

NVR-ready design

NVR-ready design allows drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.

ATA streaming support

ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.

Up to 14TB or over 9,345 hours of HD video storage

Up to 14 TB3 or over 9,345 hours4 of HD video storage support an increased number of HD cameras and allows longer data retention periods.

1M hours MTBF, 3-year limited warranty

1 M hours MTBF, 3-year limited warranty5 represents an improved total cost of ownership (TCO) with reduced maintenance costs.

Lowe power consumption

Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability.





Specifications:

Specifications 14TB 12TB 10 TB 8 TB 6 TB
Standard Model Numbers ST14000VX0008 ST12000VX0008 ST10000VX0008 ST8000VX0022 ST6000VX001
SkyHawk™ Health Management Included Yes Yes Yes Yes Yes
Interface SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s
Features and Performance
Drive Bays Supported 8+ 8+ 8+ 8+ 8+
Cameras Supported Up to 64 Up to 64 Up to 64 Up to 64 Up to 64
Max. Sustained Transfer Rate OD (MB/s) 220MB/s 220MB/s 210MB/s 210MB/s 180MB/s
Cache (MB) 256 256 256 256 256
Reliability/Data Integrity
Tarnish Resistant Yes Yes Yes Yes Yes
Load/Unload Cycles 30,000 30,000 30,000 30,000 30,000
Non-recoverable Read Errors per Bits Read, Max 1 per 10E15 1 per 10E15 1 per 10E15 1 per 10E15 1 per 10E14
Power-On Hours per Year (24×7) 8,760 8,760 8,760 8,760 8,760
Workload Rate Limit (WRL) 180 180 180 180 180
MTBF 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr
Warranty, Limited (years) 3 3 3 3 3
Power Management
Startup Current, Typical (12V, A) 1.8 1.8 1.8 2 1.8
Average Operating Power (W) 6.9W 6.9W 6.9W 9W 5W
Idling Average (W) 4.9W 4.9W 4.9W 7.6W 3.4W
Standby Mode/Sleep Mode, Typical (W) 0.8/0.8 0.8/0.8 0.8/0.8 0.6/0.6 0.25/0.25
Voltage Tolerance (5 V) ±5% ±5% ±5% ±5% ±5%
Voltage Tolerance (12 V) ±10% ±10% ±10% ±10% ±10%
Environmental/Temperature
Operating (ambient, min °C) 5 5 5 5 0
Operating (drive case, max °C) 70 70 70 70 70
Non-operating (ambient, min °C) -40 -40 -40 -40 -40
Physical
Height (mm/in, max) 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in 26.11mm/1.028in
Width (mm/in, max) 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in
Depth (mm/in, max) 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in
Weight (lb/g) 690g/1.521lb 690g/1.521lb 690g/1.521lb 780g/1.72lb 610g/1.345lb
Carton Unit Quantity 20 20 20 20 20
Cartons per Pallet / Cartons per Layer 40/8 40/8 40/8 40/8 40/8

Specifications 6TB 4TB 3TB 3TB 2TB
Standard Model Numbers ST6000VX0023 ST4000VX007 ST3000VX009 ST3000VX010 ST2000VX008
SkyHawk™ Health Management Included Yes Yes - - -
Interface SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s
Features and Performance
Drive Bays Supported 8+ 8+ 1 to 8 1 to 8 1 to 8
Cameras Supported Up to 64 Up to 64 Up to 64 Up to 64 Up to 64
Max. Sustained Transfer Rate OD (MB/s) 195MB/s 190MB/s 180MB/s 190MB/s 180MB/s
Cache (MB) 256 64 256 64 64
Reliability/Data Integrity
Tarnish Resistant Yes Yes Yes Yes Yes
Load/Unload Cycles 30,000 30,000 30,000 30,000 30,000
Non-recoverable Read Errors per Bits Read, Max 1 per 10E15 1 per 10E15 1 per 10E15 1 per 10E14 1 per 10E14
Power-On Hours per Year (24×7) 8,760 8,760 8,760 8,760 8,760
Workload Rate Limit (WRL) 180 180 180 180 180
MTBF 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr 1,000,000hr
Warranty, Limited (years) 3 3 3 3 3
Power Management
Startup Current, Typical (12V, A) 2 1.8 1.8 1.8 1.8
Average Operating Power (W) 9W 5.5W 3.5W 5.6W 5.6W
Idling Average (W) 7.2W 3.2W 2.5W 4W 4W
Standby Mode/Sleep Mode, Typical (W) 0.6/0.6 0.25/0.25 0.25/0.25 0.5/0.5 0.5/0.5
Voltage Tolerance (5 V) ±5% ±5% ±5% ±5% ±5%
Voltage Tolerance (12 V) ±10% ±10% ±10% ±10% ±10%
Environmental/Temperature
Operating (ambient, min °C) 5 0 0 0 0
Operating (drive case, max °C) 70 70 70 70 70
Non-operating (ambient, min °C) -40 -40 -40 -40 -40
Physical
Height (mm/in, max) 26.11mm/1.028in 26.11mm/1.028in 20.2mm/0.795in 26.11mm/1.028in 26.11mm/1.028in
Width (mm/in, max) 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in 101.85mm/4.01in
Depth (mm/in, max) 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in 146.99mm/5.78in
Weight (lb/g) 705g/1.55lb 635g/1.4lb 490g/1.08lb 610g/1.35lb 610g/1.345lb
Carton Unit Quantity 20 20 25 20 20
Cartons per Pallet / Cartons per Layer 40/8 40/8 40/8 40/8 40/8
